2-5mm Processing Thickness CNC Flat Iron Hoop Forming Machine 30mm Min. Diameter

Product Categories

Jinan Auten Machinery Co., Ltd

Trust Seal

Verified Supplier

Credit Check

Supplier Assessment

Contact Now

Name: 25mm Processing Thickness CNC Flat Iron Hoop Forming Machine 30mm Min Diameter
Brand: Auten
Price: 1 USD

Cut-off cylinder : 150*50

Punching cylinder : 125*30

Packaging Details : Wooden case

Price : Negotiable

Feed Roller Material : Cr12MoV

Model Number : FF50

MOQ : 1 set

Delivery Time : 60 days

Certification : ISO9001

Telescopic servo motor : 1KW

Bending servo motor : 3kw/1 unit

Brand Name : Auten

Payment Terms : L/C, T/T

Mold Material : DC53

Place of Origin : China

Supply Ability : 200 sets/year

Dimensions : 2.2×1.6×1.8m

Hydraulic power station motor : 7.5KW

Contact Now

2-5mm Processing Thickness CNC Flat Iron Hoop Forming Machine 30mm Min. Diameter

Product Application:

Mainly used for clamp processing in industries such as transportation, power and seismic bracing.

Product Parameter Configuration Table:

Model	FF50-5
Processing width	20-50mm
Processing thickness	2-5mm
Min. diameter	30mm
Max. diameter	1500mm
Max. feeding speed	55m/min
Max. bending speed	800°/sec
Punching cylinder	125*30
Feeding servo motor	3kw/1 unit
Cut-off cylinder	150*50
Bending servo motor	3kw/1 unit
Hydraulic system	Huade
Telescopic servo motor	1kw
Electrical control system	Weichuang / Xinjie
Hydraulic power station motor	7.5kw
Mold Material	DC53
Feed Roller Material	Cr12MoV
Dimensions	2.2×1.6×1.8m
